Zoomlion Factory Fd30 3ton 3.5ton Material Handling Equipment

1 / 5

Zoomlion Factory Fd30 3ton 3.5ton Material Handling Equipment

Customization:	Available
After-sales Service:	One Year
Warranty:	One Year

Send Inquiry

Product Description

Overview & Basic Info

Model NO.FD30Z

TypeDiesel Forklift

Load Capacity1T - 5T

Rated Capacity3000 Kg

PowerDiesel Engine

Lift Height3000~5000mm

Load Center500mm

Traveling Speed20 Km/H

Overhead Guard Height2170 mm

ConditionNew

Product Description

3 Tons Inside Container Operation Forklift Truck FD30Z

Safe & Green

Protective measures for the parking brake.
Vehicle emission complies with the latest environmental protection standards.
Grid type roof for excellent operation field of sight and reliability.
High-strength J-type steel channels with composite rollers for stability.

Advanced Design

Optimized running speed and improved operation efficiency.
Counterweight ventilation area increased by 10% for superior cooling.
Sedan-type double-handle combination switch for easy operation.
Shock-absorption treated connections lower vehicle vibration by 30%.
Vertical buffer function in the lifting system to decrease mast impact.

Comfortable & Practical

Fresh coating with an attractive, reasonably matched color tone.
Wide steps and broad driving space to reduce operator fatigue.
Middle exhaust tailpipe effectively prevents dust raising.
Satisfactory conical sealing in hydraulic joints prevents oil leaks.
Brand new control handle and wide operation space.

Product Parameters

Characteristics	Specifications	Unit	FD30Z	FD35Z	FD38Z
Power	Type	-	Diesel	Diesel	Diesel
Capacity	Rated Capacity	kg	3000	3500	3800
Load	Center of load	mm	500	500	500
Lifting	Lifting height	mm	3000	3000	3000
Forks	L×W×H	mm	1070×125×45	1070×125×45	1070×150×50
Speed	Max. Traveling (Loaded)	km/h	20	20	20
Engine	Model	-	QC490GP	QC490GP	QC495G
Dimensions	Overall Length (w/o fork)	mm	3895	3895	3966

Frequently Asked Questions

1. What is the rated load capacity of the FD30Z model?

The FD30Z diesel forklift has a rated load capacity of 3000 kg (3 tons) with a 500mm load center.

2. Is this forklift suitable for working inside shipping containers?

Yes, the FD30Z is specifically designed for inside container operations, featuring a mast and overhead guard configuration that allows for efficient maneuverability in confined spaces.

3. What kind of engine and transmission does it use?

The unit is powered by a high-performance diesel engine (QC490GP) and features an efficient 1/1 automatic transmission for smooth operation.

4. What are the main safety features of this forklift?

Key safety features include a vertical buffer function for the lifting system to reduce mast shock, a grid-type roof for better visibility, and specific protective measures for the parking brake.

5. Does the vehicle meet environmental standards?

Yes, the vehicle emission system is designed to comply with the latest environmental protection standards, making it a "Safe & Green" choice for material handling.
