Heavy Duty China 50ton Material Handling Equipment with Factory Price

Customization: Available
Certification: ISO9001
Condition: New

Product Description

Basic Info.

Model NO.
swcmh50
Maximum Lifting Height
10-15m
Maximum Lifting Weight
>16t
Shaft Number
2
Crane Jib
Two-Arm
Type
Folding
Max. Lifting Height
12 M
Max. Working Radius
13.5 M
Hydraulic System
Kawasaki
Warranty
One Year
Color
Yellow
Transport Package
Nude
Specification
ISO
HS Code
84314990
Production Capacity
100 PCS / Year

Product Description

Main Features of Crawler Material Handlers SWCMH500
⚙️
Increased Engine Output

Engine output has been increased, compared to the predecessor models, giving the system more torque for more powerful and faster movement. Furthermore, load peaks are compensated cleverly, meaning maximum torque is available at all times for maximum handling capacity.

🔄
High Swing Torque

The separate hydraulic pump in the closed slewing circuit only supplies hydraulic fluid to the swing mechanism. The maximum delivery volume is thus available at any time for turning the uppercarriage for fast and dynamic rotational movements.

🕹️
Sensitive Hydraulics

The optimal harmonisation between the engine and the control valve allows a fast and direct response from the hydraulics to the input command. This is controlled proportionally to enable smooth and gentle movements to be executed when the joystick is moved.

🛋️
Cabin with Ergonomic Design

The modern cab design provides excellent conditions for healthy, concentrated and productive work in maximum comfort. The colour touchscreen display, the controls and operator's seat Comfort are all coordinated to form a perfect ergonomic unit.

Dual Power System: Electric power (185hp) + Diesel power (270hp)
Hydraulic Transmission: 2.0 m³ clamshell bucket, A/C included.
Optional Attachments: lifting magnet; five peel grab, sorting grab, log grapple etc.
Dimensions Parameters
Machine length13706mm
Machine height3443mm
Machine width3340mm
Track length4947mm
Maximum lift height of the cab5143mm
Tail turning radius4412mm
Turntable height off the ground1293mm
Turntable width3265mm
Width of walking platform627mm
The cab optionsFixed cab / heightened cab / lift-able cab
Technical Parameters
Engine Power206kw
Electric Motor132kw
Fuel Tank330L
Walking Speed2.5/4.2km/h
Max. Traction Force228KN
Grade Ability30%
Max. Hydraulic Flow2 x 320L/min
Max. Working Pressure31MPa
Total Weight50t
Max. Lifting Moment60t.m

Frequently Asked Questions

What is the power configuration of this material handler?
This model features a dual power system, combining a 270hp diesel engine with a 185hp (132kw) electric motor for versatile operations.
What is the maximum lifting capacity and height?
The equipment has a maximum lifting weight of over 16 tons (with a total machine weight of 50t) and can reach a lifting height of 10-15 meters depending on the boom configuration.
Which hydraulic system does the machine use?
The machine is equipped with a high-performance Kawasaki hydraulic system, featuring a separate pump for the closed slewing circuit to ensure fast and dynamic rotational movements.
Are there different cabin options available?
Yes, the cab is optional and can be configured as a fixed cab, a heightened cab, or a lift-able cab to suit specific job site visibility requirements.
What attachments can be used with this material handler?
While it comes standard with a 2.0 m³ clamshell bucket, it also supports optional lifting magnets, five-peel grabs, sorting grabs, and log grapples.
What is the warranty period for this equipment?
The product comes with a standard one-year warranty, ensuring reliability and support for your industrial operations.
