| Category | Component / Parameter | Details |
|---|---|---|
| Solution Components | DWS Parcel Pulling Section | Adjust posture for optimal weighing angle |
| DWS Single-scale Section | Automatic weight detection and recording | |
| DWS Buffer Section | Information processing of scanned items | |
| DWS Six-sided Scanning | Full barcode identification and collection | |
| Working Parameters | Speed | 1.5 ~ 2m/s |
| Efficiency | 6000 pieces/hour | |
| Field of View | No Blind Area | |
| Weighing Performance | Max Weight | ≤ 50 kg |
| Accuracy | ± 20 g (Class III) | |
| Applicability | Suitable Size | Min: 100x100x50mm | Max: 800x1500x700mm |
| Parcel Types | Flat surface waybills; various standard parcels | |
| Code Identification | Barcode Reading Rate | ≥ 99% |
| Min Barcode Width | 0.25 mm | |
| Supported Types | 1D (Code128/39/EAN), 2D (QR/DM) |
The six-sided DWS system ensures all-round scanning with no dead angles. It eliminates the need for workers to manually flip parcels to find the barcode surface, significantly increasing processing speed.
The system is designed for high-speed operation, achieving an efficiency of up to 6,000 pieces per hour with a belt speed of 1.5 to 2 meters per second.
The DWS-M-100 features a Class III precision weighing section with a measurement accuracy of ±20g for objects weighing up to 50kg.
The system supports a wide range of formats, including 1D codes like Code128, Code39, and EAN, as well as 2D codes such as QR and DM, with a reading rate of over 99%.
Highly reflective or transparent parcels may have inaccurate volume measurements. Additionally, severely damaged waybills, cylindrical/spherical packages, or excessively wrinkled surfaces may affect identification performance.
Yes, the collected data can be connected in real-time to backend systems like swing wheel sorters, linear high-speed sorters, and cross-belt sorters for a fully automated workflow.
