Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
1 / 5
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park
Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park

Large Truck X-ray Security Inspection System Is an Accurate and Efficient Large Equipment for Vehicle Safety Inspection in Logistics Park

Customization: Available
After-sales Service: Remote Support
Warranty: 1 Year
Send Inquiry

Product Description

Basic Specification
Model NO.
IWILDT AN-48002800L
Certification
CE, ISO
Application
Security Check
Type
Industrial High-Definition X-ray Detector
Ray Energy
420kv
Penetration
100mm Thick Steel Plate
Channel Size
2.8m (W) X 4.8m (H)
Origin
China
Product Introduction

IWILDT™ AN-48002800L is an accurate and efficient large-scale X-ray security inspection system designed for vehicles in logistics parks. Utilizing advanced ray digital imaging technology, it inspects load-bearing goods without the need for unpacking or unloading.

Smart Scanning
Features car head avoidance and radiation imaging of the cargo part to ensure driver safety while maintaining inspection integrity.
High Penetration
Adopts multi-energy X-ray source cascade mode, achieving a penetration force of up to 100mm of steel plate.
Rapid Operation
In pass-through mode, the system can scan up to 60 large trucks per hour with a data acquisition speed of 0.80 meters per second.

The system generates high-resolution pseudo-color gray-level images, allowing operators to reliably analyze material, volume, and quantity to detect explosives, drugs, and other contraband.

Technical Parameters
X-ray Source Ray energy: 420kv; Side irradiation; 100mm penetration; 10mm thick lead radiation protection; Scattering angle: 100 degrees.
Detection System Modular design; L-shaped line array; 1536 pixels; CdWO4 crystal; CMOS photoelectric conversion; RJ45 communication.
Image Processing i7 Workstation; 24-inch LCD; Edge enhancement, organic/inorganic removal, real-time video, license plate recognition.
Performance Scanning speed: 5-10km/h; Absorbed dose: < 1 USV/time; Waterproof grade: IP45; Power consumption: 5kW.
Visual Display
Security Inspection System Overview
X-ray System Detail 1
X-ray System Detail 2
X-ray System Detail 3
X-ray System Detail 4
Frequently Asked Questions
Q1: What is the maximum scanning capacity of the AN-48002800L?
The system is highly efficient, capable of scanning up to 60 large trucks per hour in pass-through mode, making it ideal for high-traffic logistics parks.
Q2: Can the system detect objects through heavy steel?
Yes, the multi-energy X-ray source provides high penetration, allowing the operator to see through up to 100mm of thick steel plate.
Q3: Is the system safe for drivers and passengers?
The system includes a car head avoidance function. Radiation imaging only begins on the cargo portion of the vehicle, and the absorbed dose per scan is less than 1 USV.
Q4: What kind of threats can the X-ray system identify?
It is designed to check for explosives, drugs, weapons of mass destruction (WMDs), and other contraband by analyzing the material density and shape of goods.
Q5: Is the detection frame size customizable?
Yes, the IWILDT AN-48002800L can be customized to design the specific width and height of the detection frame to meet unique user requirements.
Q6: What image processing functions are available?
The workstation includes features such as edge enhancement, sharpening, image inversion, organic/inorganic matter removal, and real-time video analysis.
